The low-cost infrared reflow oven Puhui T-962 can be used for effectively soldering various SMD and BGA components. It can solder most boss-eyed or double-face PCB boards small parts (CHIP, SOP, PLCC, QFP, BGA).
The T962 may be used to automatically rework solder to correct bad solder joints, remove / replace bad components and complete small engineering models or prototypes.
- Wide welding area;
- Fully automatic soldering process;
- 8 soldering cycles are predefined;
- Powerful infrared emission and circulation of the hot air flow;
- 800 watts of energy efficient infrared heating;
- It can be programmed to follow a specific temperature profile;
- Ergonomic design;
- Buttons and an LCD display;
- A windowed drawer;
- A microprocessor-controlled oven;
- User-friendly interface;
- Easy to use.
| Model | T-962 |
| Welding area, mm | 180x235 |
| Rated Power, W | 800 |
| Heating | infrared |
| Temperature range | 0 ~ 280°C |
| Processing Time | 6 ~ 10 min |
| Power Supply | 220/110 В, 50-60 Гц |
| Dimensions, mm | 310х260х180 |
| Weight, kg | 7 |
